Overview

Basic Info.

Model NO.
Pressing/Drop Forged/Casted iron
Supporting Mode
Projecting Scaffolding
Lapping Form
Double Scaffolding
Erection Position
External Scaffolding
Move Method
Attached Lifting Scaffolding
Scaffolding Part Type
Scaffolding Coupler
Construction Properties
Building Scaffold
Color
Silver or Gold
Hscode
7308900000
Certificate
ISO9001/ISO14001
Surface Treatment
Elec-Galvanized, Hot-Galvanized
Transport Package
Pallet
Specification
48.6*48.6mm
Trademark
ZHIYI(20 years Manufacturing experience)
Origin
Tianjin, China
HS Code
7308900000
Production Capacity
1000tons Per Month

Product Description


Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut

Product Description

Item:Scaffolding coupler/clamp, Scaffolding coupler is used to assemble tube-and coupler scaffolding system.Special marking can be as per customers' required.
Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut
  1. Pressed scaffolding coupler fittings:
NAME STANDARD SIZE WEIGHT / KG MATERIAL SURFACE TREATMENT
Double coupler BS1139 48.3mm 0.82 Q235 Eletro-Galvanized
Swivel coupler BS1139 48.3mm 1.00 Q235 Eletro-Galvanized
Half Coupler BS1139 48.3mm 0.45 Q235 Eletro-Galvanized
Putlog coupler BS1139 48.3mm 0.58 Q235 Eletro-Galvanized
Board retaining coupler BS1139 48.3mm 0.57 Q235 Eletro-Galvanized
Sleeve coupler BS1139 48.3mm 1.00 Q235 Eletro-Galvanized
Inner Joint Pin Coupler BS1139 48.3mm 0.60 Q235 Eletro-Galvanized
Beam Coupler BS1139 48.3mm 1.00 Q235 Eletro-Galvanized
Limpet Coupler BS1139 48.3mm 0.32 Q235 Eletro-Galvanized
Ladder Coupler BS1139 48.3mm 0.45 Q235 Eletro-Galvanized

2. Drop Forged Scaffolding Coupler Fittings:
NAME STANDARD SIZE WEIGHT / KG MATERIA SURFACE TREATMENT
Double Coupler BS1139/EN74 48.3mm 0.98 Q235 Electro-Gal. / HDG
Swivel Coupler BS1139/EN74 48.3mm 1.12 Q235 Electro-Gal. / HDG
Half Coupler BS1139/EN74 48.3mm 0.52 Q235 Electro-Gal. / HDG
Board Retainning Coupler BS1139/EN74 48.3mm 0.62 Q235 Electro-Gal. / HDG
Putlog Coupler BS1139/EN74 48.3mm 0.63 Q235 Electro-Gal. / HDG
Girder/Beam Coupler BS1139/EN74 48.3mm 1.50 Q235 Electro-Gal. / HDG
Sleeve Coupler BS1139/EN74 48.3mm 1.00 Q235 Electro-Gal. / HDG
Inner Joint Coupler BS1139/EN74 48.3mm 1.05 Q235 Electro-Gal. / HDG

3.  Casted iron Scaffolding Coupler Fittings:
NAME STANDARD SIZE WEIGHT / KG MATERIA SURFACE TREATMENT
Double Coupler BS1139 48.3mm 1.00 Ductile iron Painted
Swivel Coupler BS1139 48.3mm 1.00 Ductile iron Painted
Inner Joint Coupler BS1139 48.3mm 1.00 Ductile iron Painted


Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut

Product Application

Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut

Packaging & Shipping

Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut

Related Products

Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut

Company Profile

Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity NutTianjin Zhiyi Metal Products Co. Ltd was founded in 2002, which holds ten million RMB registered capital. Our company is located in Tianjin, a port city in northern China, and its covers an area of 27000 square meter
Our company was specialized in the design and manufacture of metal products. The products of our factory have always been wildly recognized by both abroad and domestic customers in the past ten years. In the year 2008, our company was officially designated as the main supplier of assistant project by Tianjin government. And our products that were exported to west Asia and South American was wildly popular among our customers.
The main metal products produced by our company include steel props, scaffolding, steel plank , LvL plank , plywood,Base jack, scaffolding coupler, formwork accessories, galvanized pipe ,H20 beam,ground screw, solar stand, C / Z /H section steel , other building material etc.
Our company has professional managerial personnel and well-qualified technical team. From the very start of our company, we always insist on the concept of "Innovation, quality, service, economy, dedication, and apparition." Believing products quality can be our vitality, time will prove our reputation and reasonable price is our competitiveness, our company stands tall in the economic capital of north China.
Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut
Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut

Certifications

Types of Scaffolding Butterfly Joint G Toe Board Sleeve Double Clamps Swivel Bracing Coupler Name Load Capacity Nut




FAQ

How to buy your ideal products?
You can provide us your drawing, and we will produce as your drawing.
Or we can design as your requirements if you do not have a clear plan.
How to pay?
TT and L/C are acceptable and TT will be more appreciated.
What is the delivery time?
It depends on order quantity.
Generally, the delivery time will be within 15 to 30 days.
How about our product quality?
Our steel prop piles are manufactured with first quality materials
What is steel quality?
This system is built from Q235 steel conical pipe with welded blades,
and can be applied in a wide variety of different geological locations.
How to order from Zhiyi ?
Buyer Send Enquiry →Get Zhiyi Quotation → Order Confirmation
→ Buyer Arrange 30% Deposit → Production Started upon Receipt of Deposit
