Basic Info.
Model NO.
MP-27
Supporting Mode
Floor Type Scaffolding
Lapping Form
Full Scaffolding
Erection Position
External Scaffolding
Move Method
Attached Lifting Scaffolding
Scaffolding Part Type
Scaffolding Frames
Construction Properties
Building Scaffold
Sruface Treatment
Pre-Galvanized
Steel Grade
Q195 / Q235
Color
Silver
Certificate
SGS/ISO
Width
0.5-4m
Thickness
0.8-2.0mm
Height
38mm/40mm/45mm/50mm/63mm/76mm
Support
Flat / Square /Ladder Type
End Cap
Cover / Insert
Application
Building/Tunnel/Bridge Construction
Delivery Time
15-20days
MOQ
1 Piece
OEM
Available
Transport Package
by Pallet, Suitable for Sea Transport
Specification
210mm/240mm/250mm/225mm/230mm/300mm/320mm
Trademark
HUAYOU
Origin
China
HS Code
7308400000
Production Capacity
40 Containers / Month
Product Description
Scaffolding Metal Plank is an important component to provide support for construction work. It helps workers to walk through and work on the different scaffolding systems. With its various design and size, Huayou Scaffolding Metal Plank has become the necessary component of the scaffolding system and is widely used by different market clients. Warmly welcome your inquiry.
DETAIL SIZE:
PRODUCTION PROCESS:
PACKAGE & LOADING:
-By pieces or by bundle or by pallet, as requested.
CERTIFICATE:
COMPANY PROFILE:
Tianjin Huayou Scaffolding Co., Ltd is located in Tianjin City, which is the largest manufacturing base of steel and scaffolding products. Furthermore, it is the north biggest port city that easier to transport cargo to all over the world.
Warmly welcome your inquiry support.
OTHER RELATED PRODUCTS:
FAQ:
Q1: Where is the loading port?
A: Tianjin Xin port
Q2: What's the MOQ of the product?
A: Different item has different MOQ, which can be negotiated.
Q3: What certificates do you have?
A: We have ISO 9001, SGS, etc.
Q4: Can I get some samples?
A: Yes, the Sample is free, but the shipping cost is on your side.
Q5: How long is the production cycle after ordering?
A: Generally need around 20-30 days.
Q6: What is the payment methods?
A: T/T or 100% irrevocable LC at sight, can be negotiated.
| Name: | Metal Plank / Steel Board |
| Material: | Q195 / Q235 |
| Surface: | Pre-galvanized; Painted; Powder Coated; HDG |
| Support: | Normal Flate Bar; Box / Square type; Ladder Type |
| Size Width: | 200mm, 210mm, 240mm, 225mm, 250mm, 230mm, 300mm, 320mm |
| Package: | By pieces, by the bundle, by pallet |
| Loading: | 40ft |
DETAIL SIZE:
| WIDTH (MM) | HEIGHT (MM) | TKN (MM) | LENGTH (MM) | STIFFENNER TYPE |
| 210 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 1000 | FLATE/BOX/LADDER |
| 210 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 2000 | FLATE/BOX/LADDER |
| 210 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 3000 | FLATE/BOX/LADDER |
| 210 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 4000 | FLATE/BOX/LADDER |
| 240 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 1000 | FLATE/BOX/LADDER |
| 240 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 2000 | FLATE/BOX/LADDER |
| 240 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 3000 | FLATE/BOX/LADDER |
| 240 | 45 | 1.0/1.1/1.2/1.5/1.8/2.0 | 4000 | FLATE/BOX/LADDER |
| 250 | 40/50 | 1.0/1.1/1.2/1.5/1.8/2.0 | 1000 | FLATE/BOX/LADDER |
| 250 | 40/50 | 1.0/1.1/1.2/1.5/1.8/2.0 | 2000 | FLATE/BOX/LADDER |
| 250 | 40/50 | 1.0/1.1/1.2/1.5/1.8/2.0 | 3000 | FLATE/BOX/LADDER |
| 250 | 40/50 | 1.0/1.1/1.2/1.5/1.8/2.0 | 4000 | FLATE/BOX/LADDER |
| 225 | 38/63 | 1.5/1.8/2.0 | 1000 | BOX |
| 225 | 38/63 | 1.5/1.8/2.0 | 2000 | BOX |
| 225 | 38/63 | 1.5/1.8/2.0 | 3000 | BOX |
| 225 | 38/63 | 1.5/1.8/2.0 | 4000 | BOX |
| 230 | 63 | 1.5/1.8/2.0 | 1000 | FLATE |
| 230 | 63 | 1.5/1.8/2.0 | 2000 | FLATE |
| 230 | 63 | 1.5/1.8/2.0 | 3000 | FLATE |
| 230 | 63 | 1.5/1.8/2.0 | 4000 | FLATE |
| 300 | 50 | 1.5/1.8/2.0 | 1000 | FLATE |
| 300 | 50 | 1.5/1.8/2.0 | 2000 | FLATE/BOX |
| 300 | 50 | 1.5/1.8/2.0 | 3000 | FLATE/BOX |
| 300 | 50 | 1.5/1.8/2.0 | 4000 | FLATE/BOX |
| 320 | 76 | 1.5/1.8/2.0 | 730 | ROUND |
| 320 | 76 | 1.5/1.8/2.0 | 1090 | ROUND |
| 320 | 76 | 1.5/1.8/2.0 | 1570 | ROUND |
| 320 | 76 | 1.5/1.8/2.0 | 2070 | ROUND |
| 320 | 76 | 1.5/1.8/2.0 | 2570 | ROUND |
| 320 | 76 | 1.5/1.8/2.0 | 3070 | ROUND |
PRODUCTION PROCESS:
PACKAGE & LOADING:
-By pieces or by bundle or by pallet, as requested.
CERTIFICATE:
COMPANY PROFILE:
Tianjin Huayou Scaffolding Co., Ltd is located in Tianjin City, which is the largest manufacturing base of steel and scaffolding products. Furthermore, it is the north biggest port city that easier to transport cargo to all over the world.
We specialize in the production and sales of various scaffolding products, such as Ringlock system, steel Board, Frame system, Jack base, Pipes and fittings, Couplers, Cuplock system, Kwickstage system, Aluminuim system and other scaffolding or formwork accessories. With the effort of over 10 years experience team, Huayou products has been exported to different countries and clients cover different areas like South East Asia market, Middle East Market, Europe, America, Austrilia etc.
Our principle: "Quality First, Customer Foremost and Service Ultmost." We devote ourselves to meet your requirements and promote our mutually beneficial cooperation.
Warmly welcome your inquiry support.
OTHER RELATED PRODUCTS:
FAQ:
Q1: Where is the loading port?
A: Tianjin Xin port
Q2: What's the MOQ of the product?
A: Different item has different MOQ, which can be negotiated.
Q3: What certificates do you have?
A: We have ISO 9001, SGS, etc.
Q4: Can I get some samples?
A: Yes, the Sample is free, but the shipping cost is on your side.
Q5: How long is the production cycle after ordering?
A: Generally need around 20-30 days.
Q6: What is the payment methods?
A: T/T or 100% irrevocable LC at sight, can be negotiated.
