Basic Info.
Name1
Pole Shore
Name2
Steel Prop
Adjustable
6′6" - 11′
a Range
2.1meters - 3.5meters
Raw Material
Q235 Q345b 40cr , Cast Iron Steel
Loading Capacity
18000-38000lbs
Usage
Construction Formwork Discharge Vessels
Transport Package
by The Steel Pallet
Specification
customized can be 48/60, 76/63
Trademark
CJ
Origin
Hebei Cangzhou
HS Code
7308400000
Production Capacity
22000
Product Description
| Production Name | Concrete formwork telescopic shoring steel prop ,adjustable acro jack steel props steel prop ,scaffolding steel props, steel props for construction,adjustable steel props, steel shoring prop scalfolding,adjustable post shore,steel pole shore scaffolding formwork |
| Outer Diameter | 48mm--60mm; 40mm--48mm;60--76mm |
| Prop Thickness | 1.5mm--3mm |
| Length | 600mm--5000mm |
| Standard | GB, ANSI, ASME, ASTM, JIS, DIN, BS, EN |
| Material | Q195,Q235, Q345 |
| Package | in pallets or in bundle or in bulk |
| Surface Treatment | dipping painted / galvanized |
| Type | heavy duty or light duty |
| Application | slab or formworking supporting |
| Weight | 4.74kg--30kg |
Kinds of steel post shore can be customized by your request : Galvanized Steel Prop 63.5mm/76mm Series
Adjustable length:2-3.5 Meters
63.5 inner tube length:2 Meters*thickness 4mm(Q345 Seamless pipe)
76 out tube length:1.5 Meters *thickness 3.25mm
76 thread length: 0.28 Meter 4mm*thickness
Base plate:150*150*6mm( butterfly type)
Pin diameter:18mm(40Cr quenched material)
Nut: 1Kgs type
Weight:24.5kg(theoretical weight)
20' container loading Qty: 1040 PCS
Here is North America Heavy type Post Shore for SGS:
Galvanized Steel Prop 60mm/76mm Series
Adjustable length:2-3.5 Meters
60 inner tube length:2 Meters*thickness 3.5mm(Q235 welding pipe)
76 out tube length:1.5 Meters *thickness 3.25mm
76 thread length: 0.28 Meter 4mm*thickness
Base plate:150*150*6mm( butterfly type)
Pin diameter:18mm(40Cr quenched material)
Nut: 1Kgs type
Weight:22.5kg (theoretical weight)
20' container loading Qty: 1150 PCS
